PC02T Waterborne Epoxy insulating and oil resistant pioneering coating for crude oil tank interior surface （Primer and Topcoat)
Product Description：
This waterborne epoxy coating series is specially designed for internal anti-corrosion of oil storage tanks and is prepared with waterborne epoxy resin and related functional materials. The waterborne paint products for oil storage tanks are divided into two types: static conductive and non-static conductive. It is a two-component epoxy coat with a ratio of component A to component B of 10:1.
This product is of the non-static conductive series and has insulation function. The insulation series is mainly used for the bottom plate of crude oil tanks and the first ring plate, the top inside the floating roof and tank accessories.For construction inside the tank, the lighting voltage can be appropriately increased without fire hazard to ensure the construction quality.
There are two models of products: primer and topcoat:
PC02C Primer Waterborne Epoxy insulating and oil resistant coating for crude oil tank interior surface Primer
PC02C Topcoat Waterborne Epoxy insulating and oil resistant coating for crude oil tank interior surface Topcoat
Application use:
Suitable for anti-corrosion coating inside crude oil storage tanks and mechanical equipment with higher anti-corrosion requirements. Especially for the bottom plate of crude oil tanks and the first ring plate, the top inside the floating roof and tank accessories.
Product performance parameters:
| Model | PC02T Primer | PC02T Topcoat | ||||
| Gloss | Matte | Matte | ||||
| Popular colors | Iron Red,Gray,Customized colors | Gray,Customized colors | ||||
| Solids by volume | 50 ±2% | 50 ±2% | ||||
| Density | 1.24 kg/l | 1.32 kg/l | ||||
| Wet film thickness | 100-120 μm | 100-120 μm | ||||
| Dry film thickness | 50-60 μm | 50-60 μm | ||||
| Theoretical coating rate | 6.1-5 ㎡/l | 6.1-5 ㎡/l | ||||
| Adhesion | Grade 0-1 | Grade 0-1 | ||||
| Impact resistance | 50 kg / cm | 50 kg / cm | ||||
| Drying time / Temperature | 15℃ | 25℃ | 35℃ | 15℃ | 25℃ | 35℃ |
| Surface dry (humidity 60%) | 4h | 2h | 1h | 4h | 2h | 1h |
| Hard dry (humidity 60%) | 8h | 5h | 3h | 8h | 5h | 3h |
